Specifications of BMW R 1200 GS
Bike Discontinued in Oct, 2019
BMW R 1200 GS Specifications
Mileage (ARAI) | 16 Kmpl |
Displacement | 1170 cc |
Engine Type | Air/liquid-cooled, twin-cylinder, 4-stroke, DOHC engine |
No. of Cylinders | 2 |
Max Power | 125 PS @ 7750 rpm |
Max Torque | 125 Nm @ 6500 rpm |
Front Brake | Disc |
Rear Brake | Disc |
Fuel Capacity | 20 L |
Body Type | Adventure Tourer Bikes |
BMW R 1200 GS Features
ABS | Dual Channel |
Riding Modes | Rain,Road |
Adjustable Windshield | Yes |
LED Tail Light | Yes |
Speedometer | Analogue |
Odometer | Digital |
Tripmeter | Digital |
Fuel gauge | Yes |
Tachometer | Analogue |
BMW R 1200 GS Specifications
Engine and Transmission
Engine Type Refers to the design and configuration of the engine. Most petrol bikes typically use either a single-cylinder, twin-cylinder, or occasionally a multi-cylinder (like a four-cylinder) engine. | Air/liquid-cooled, twin-cylinder, 4-stroke, DOHC engine |
Displacement | 1170 cc |
Max Torque Represents the highest rotational force output by the engine, usually measured in Newton-meters (Nm) or pound-feet (lb-ft). It indicates the engine's pulling power. | 125 Nm @ 6500 rpm |
No. of Cylinders Indicates the total count of combustion cylinders in the engine. Common configurations include single-cylinder, twin-cylinder, and four-cylinder setups. | 2 |
Cooling System Describes the method used to dissipate heat from the engine. Petrol bikes often use air-cooling or liquid-cooling systems to maintain optimal operating temperatures. | Air and Liquid Cooled |
Valve Per Cylinder Refers to the number of intake and exhaust valves present in each cylinder. Most modern petrol bike engines have two or four valves per cylinder. | 4 |
Starting Describes how the engine is initiated. Most petrol bikes use electric starters, kick starters, or both, to commence engine operation. | Self Start Only |
Fuel Supply | Fuel Injection |
Clutch Enables the rider to disconnect the engine from the transmission temporarily, allowing for gear changes and neutral operation. | Oil Lubricated Clutch, Hydraulically Operated |
Gear Box Indicates the arrangement of gears that transmit power from the engine to the wheels, allowing the rider to adjust speed and torque. | 6 Speed |
Bore These measurements describe the diameter (bore) and length (stroke) of the cylinder in the engine. They directly affect an engine's performance characteristics. | 101 mm |
Stroke These measurements describe the diameter (bore) and length (stroke) of the cylinder in the engine. They directly affect an engine's performance characteristics. | 73 mm |
Compression Ratio Reflects the ratio of the maximum volume in the cylinder (when the piston is at the bottom) to the minimum volume (when the piston is at the top) during the engine cycle. Higher compression ratios generally lead to more efficient combustion. | 12.5:1 |
Features
Instrument Console This refers to the display panel on a petrol bike that shows essential information like speed, RPM, fuel level, and other indicators such as engine temperature and gear position. | Analogue and Digital |
Speedometer Displays the current speed of the bike in kilometers per hour (km/h) or miles per hour (mph), providing crucial information for safe riding. | Analogue |
Techometer | Analogue |
Tripmeter Tracks the distance traveled during a specific journey or trip, enabling riders to monitor their mileage for individual rides. | Digital |
Odometer Shows the total distance covered by the bike since its inception, providing a comprehensive record of its usage | Digital |
Additional Features Of Variant This refers to unique features or upgrades specific to a particular model or variant of the petrol bike, which may include enhanced performance components, aesthetic improvements, or technology integrations. | Riding Modes, Automatic Stability Control , BMW Motard Integral ABS, Power Socket, On Board Computer, Anti Hopping Clutch, Luggage Rack, HandBrake and Clutch Lever Adjustable, Adjustable Windscreen |
Seat Type | Split |
Clock | Yes |
Passenger Backrest | No |
Stepup Seat | Yes |
Passenger Footrest Provides a designated area for the pillion passenger to rest their feet comfortably during rides. | Yes |
Carry hook | No |
Features and Safety
Speedometer Displays the current speed of the bike in kilometers per hour (km/h) or miles per hour (mph), providing crucial information for safe riding. | Analogue |
Tachometer | Analogue |
Odometer Shows the total distance covered by the bike since its inception, providing a comprehensive record of its usage | Digital |
Tripmeter Tracks the distance traveled during a specific journey or trip, enabling riders to monitor their mileage for individual rides. | Digital |
Fuel Gauge | Digital |
Pass Switch | Yes |
Clock | Yes |
Riding Modes | Rain,Road |
Adjustable Windscreen | Yes |
Additional Features This refers to unique features or upgrades specific to a particular model or variant of the petrol bike, which may include enhanced performance components, aesthetic improvements, or technology integrations. | Riding Modes, Automatic Stability Control , BMW Motard Integral ABS, Power Socket, On Board Computer, Anti Hopping Clutch, Luggage Rack, HandBrake and Clutch Lever Adjustable, Adjustable Windscreen |
Carry Hook | No |
Stepup Seat | Yes |
Passenger Footrest Provides a designated area for the pillion passenger to rest their feet comfortably during rides. | Yes |
Mileage and Performance
ARAI Mileage | 16 Kmpl |
Acceleration (0-100 Kmph) | 3.4s |
Chassis and Suspension
Body Type | Adventure Tourer Bikes |
Dimensions and Capacity
Width These dimensions describe the physical size of the bike. Width represents the distance across the widest part of the bike, length is the distance from front to back, and height is the vertical measurement from the ground to the highest point of the bike. | 952.5 mm |
Length | 2207 mm |
Height | 1412 mm |
Fuel Capacity | 20 L |
Fuel Reserve | 4 L |
Saddle Height Indicates the distance from the ground to the top surface of the bike's seat, influencing rider comfort and accessibility, especially for shorter or taller individuals. | 850 mm |
Wheelbase | 1507 mm |
Dry Weight | 216 kg |
Kerb Weight | 244 kg |
Total Weight | 460 kg |
Load Carrying Capacity | 216 kg |
Electricals
Headlight | LED with DRL |
Tail Light | LED |
Turn Signal Lamp | LED |
LED Tail Lights | Yes |
Alternator | 510 W |
Tyres and Brakes
Front Brake Diameter Refers to the diameter of the disc or drum used for the front brake system on a petrol bike, influencing braking performance and heat dissipation. | 305 mm |
Rear Brake Diameter Indicates the diameter of the disc or drum used for the rear brake system, contributing to the bike's overall braking effectiveness and control. | 276 mm |
Radial Tyre | Yes |
Performance
0-100 Kmph (sec) | 3.4s |
Top Speed | 200 kmph |
Motor & Battery
Peak Power | 125 PS @ 7750 rpm |
Drive Type Describes the configuration of the drivetrain, such as front-wheel drive, rear-wheel drive, or all-wheel drive, affecting traction and handling characteristics. | Shaft Drive |
Transmission | Manual |
Charging
Charging At Home | No |
Charging At Charging Station | No |
Underpinnings
Suspension Front | BMW Motorrad Telelever; stanchion diameter 37 mm, central spring strut |
Suspension Rear | Cast aluminium single-sided swing arm with BMW Motorrad Paralever; WAD strut (travel-related damping), spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping ad |
Brakes Front | Disc |
Brakes Rear | Disc |
ABS | Dual Channel |
Tyre Size | Front :-120/70-R19, Rear :-170/60-R17 |
Wheel Size | Front :-19 inch, Rear :-17 inch |
Wheels Type | Alloy |
Frame | Wet clutch with an anti-hopping function, hydraulic activation |
Tubeless Tyre | Tubeless |
