Specifications of Honda Dio
The Honda Dio is powered by a 109.51 cc air-cooled engine which produces 7.85 PS @ 8000 rpm of power. It has a fuel tank of 5.3 L and a claimed mileage of 50 kmpl. The Honda Dio starts at Rs 70,211 and goes up to Rs 77,712 (ex-showroom, Delhi). It is available in three variants.
Honda Dio Specifications
Mileage (Overall) | 50 kmpl |
Displacement | 109.51 cc |
Engine Type | 4 Stroke, SI Engine |
No. of Cylinders | 1 |
Max Power | 7.85 PS @ 8000 rpm |
Max Torque | 9.03 Nm @ 5250 rpm |
Front Brake | Drum |
Rear Brake | Drum |
Fuel Capacity | 5.3 L |
Honda Dio Features
External Fuel Filling | Yes |
Speedometer | Analogue |
Odometer | Analogue |
Tripmeter | Analogue |
Tachometer | Analogue |
Honda Dio Specifications
Engine and Transmission
Engine Type Refers to the design and configuration of the engine. Most petrol bikes typically use either a single-cylinder, twin-cylinder, or occasionally a multi-cylinder (like a four-cylinder) engine. | 4 Stroke, SI Engine |
Displacement | 109.51 cc |
Max Torque Represents the highest rotational force output by the engine, usually measured in Newton-meters (Nm) or pound-feet (lb-ft). It indicates the engine's pulling power. | 9.03 Nm @ 5250 rpm |
No. of Cylinders Indicates the total count of combustion cylinders in the engine. Common configurations include single-cylinder, twin-cylinder, and four-cylinder setups.
| 1 |
Valve Per Cylinder Refers to the number of intake and exhaust valves present in each cylinder. Most modern petrol bike engines have two or four valves per cylinder. | 2 |
Starting Describes how the engine is initiated. Most petrol bikes use electric starters, kick starters, or both, to commence engine operation. | Self Start Only |
Fuel Supply | Fuel Injection |
Clutch Enables the rider to disconnect the engine from the transmission temporarily, allowing for gear changes and neutral operation. | Automatic Centrifugal Clutch Dry Type |
Bore These measurements describe the diameter (bore) and length (stroke) of the cylinder in the engine. They directly affect an engine's performance characteristics. | 47 mm |
Stroke These measurements describe the diameter (bore) and length (stroke) of the cylinder in the engine. They directly affect an engine's performance characteristics. | 63.121 mm |
Compression Ratio Reflects the ratio of the maximum volume in the cylinder (when the piston is at the bottom) to the minimum volume (when the piston is at the top) during the engine cycle. Higher compression ratios generally lead to more efficient combustion. | 10.0:1 |
Emission Type Specifies the level of emissions produced by the bike, conforming to regulatory standards. Petrol bikes typically adhere to norms like Euro or BS (Bharat Stage) emissions standards. | bs6-2.0 |
![Honda Honda](https://bd.gaadicdn.com/pwa/img/spacer3x2.png)
Features
Instrument Console This refers to the display panel on a petrol bike that shows essential information like speed, RPM, fuel level, and other indicators such as engine temperature and gear position. | Analogue |
Speedometer Displays the current speed of the bike in kilometers per hour (km/h) or miles per hour (mph), providing crucial information for safe riding. | Analogue |
Techometer | Analogue |
Tripmeter Tracks the distance traveled during a specific journey or trip, enabling riders to monitor their mileage for individual rides. | Analogue |
Odometer Shows the total distance covered by the bike since its inception, providing a comprehensive record of its usage | Analogue |
Additional Features Of Variant This refers to unique features or upgrades specific to a particular model or variant of the petrol bike, which may include enhanced performance components, aesthetic improvements, or technology integrations. | LED Position Light, Seat Length - 650 mm, Front Pocket, Multifunction Switch, Stylish Muffler Protector, Split Grabrail, Retractable Pillion Foot Step, eSP Technology, Silent Start Wth ACG, Side Stand Engine Cutoff (Optional) |
Seat Type | Single |
Passenger Footrest Provides a designated area for the pillion passenger to rest their feet comfortably during rides. | Yes |
Carry hook | Yes |
Underseat storage | Yes |
Features and Safety
Speedometer Displays the current speed of the bike in kilometers per hour (km/h) or miles per hour (mph), providing crucial information for safe riding. | Analogue |
External Fuel Filling | Yes |
Tachometer | Analogue |
Odometer Shows the total distance covered by the bike since its inception, providing a comprehensive record of its usage | Analogue |
Tripmeter Tracks the distance traveled during a specific journey or trip, enabling riders to monitor their mileage for individual rides. | Analogue |
Fuel Gauge | Analog |
Pass Switch | Yes |
Additional Features This refers to unique features or upgrades specific to a particular model or variant of the petrol bike, which may include enhanced performance components, aesthetic improvements, or technology integrations. | LED Position Light, Seat Length - 650 mm, Front Pocket, Multifunction Switch, Stylish Muffler Protector, Split Grabrail, Retractable Pillion Foot Step, eSP Technology, Silent Start Wth ACG, Side Stand Engine Cutoff (Optional) |
Carry Hook | Yes |
Passenger Footrest Provides a designated area for the pillion passenger to rest their feet comfortably during rides. | Yes |
Engine Kill Switch | Yes |
Mileage and Performance
Overall Mileage | 50 kmpl |
Dimensions and Capacity
Width These dimensions describe the physical size of the bike. Width represents the distance across the widest part of the bike, length is the distance from front to back, and height is the vertical measurement from the ground to the highest point of the bike. | 723 mm |
Length | 1808 mm |
Height | 1150 mm |
Fuel Capacity | 5.3 L |
Saddle Height Indicates the distance from the ground to the top surface of the bike's seat, influencing rider comfort and accessibility, especially for shorter or taller individuals. | 765 mm |
Ground Clearance | 160 mm |
Wheelbase | 1260 mm |
Kerb Weight | 103 kg |
Additional Storage | Yes |
Electricals
Headlight | Halogen |
Taillight | Bulb |
Turn Signal Lamp | Bulb |
Low Fuel Indicator | Yes |
Tyres and Brakes
Front Brake Diameter Refers to the diameter of the disc or drum used for the front brake system on a petrol bike, influencing braking performance and heat dissipation. | 130 mm |
Rear Brake Diameter Indicates the diameter of the disc or drum used for the rear brake system, contributing to the bike's overall braking effectiveness and control. | 130 mm |
Motor & Battery
Peak Power | 7.85 PS @ 8000 rpm |
Drive Type Describes the configuration of the drivetrain, such as front-wheel drive, rear-wheel drive, or all-wheel drive, affecting traction and handling characteristics. | Belt Drive |
Battery Capacity | 12V / 3AH |
Transmission | Automatic |
Underpinnings
Suspension Front | Telescopic |
Suspension Rear | Unit Swing |
Brakes Front | Drum |
Brakes Rear | Drum |
Tyre Size | Front :-90/90-12, Rear :-90/100-10 |
Wheel Size | Front :-304.8 mm,Rear :-254 mm |
Wheels Type | Black Steel Rim |
Frame | Underbone |
Tubeless Tyre | Tubeless |
