Technical Specifications of Honda Dio: Engine, Dimensions & Performance
Shortlist
Rs.70,809* onwards
EMI starts from ₹2,424
Honda Dio Specifications
| Mileage (Overall) | 50 kmpl |
| Displacement | 109.51 cc |
| Engine Type | 4 Stroke, SI Engine |
| Number Of Cylinders | 1 |
| Max Power | 7.95 PS @ 8000 rpm |
| Max Torque | 9.03 Nm @ 5500 rpm |
| Front Brake | Drum |
| Rear Brake | Drum |
| Fuel Tank Capacity | 5.3 L |
| Fuel Type | Petrol |
Honda Dio Features
| Braking Type | Combi Brake System |
| Daytime Running Lamps | Yes |
| Seat Opening Switch | Yes |
| External Fuel Filling | Yes |
| Key Shutter Lock | Yes |
| Speedometer | Analogue |
| Odometer | Analogue |
| Tripmeter | Analogue |
| Tachometer | Analogue |
| Transmission | Automatic |
What's Included with Honda Dio
| Vehicle Warranty | 3 Years or 36,000 Km |
Honda Dio Specifications
Engine and Transmission
| Displacement | 109.51 cc |
Engine Type | 4 Stroke, SI Engine |
| Number Of Cylinders | 1 |
| Valves (per cylinder) | 2 |
| Fuel Type | Petrol |
| Max Power | 7.95 PS @ 8000 rpm |
| Max Torque | 9.03 Nm @ 5500 rpm |
| Claimed Top Speed | 83 kmph |
| Flex Fuel Blend | E20 |
| Supply System | Fuel Injection |
| Starting System | Kick and Self Start |
| Cooling System | Air Cooled |
| Bore | 47 mm |
| Stroke | 63.121 mm |
| Compression Ratio | 10.0:1 |
| Emission Norm Compliance | bs6.2 |
| Spark Plugs | 1 Per Cylinder |
| Drive Type | Chain Drive |
| Transmission Type | Automatic |
| Clutch | Automatic Centrifugal Clutch Dry Type |
| Gearbox | CVT |
| Report Incorrect Specs | |
Don't miss out on the best offers this September
Features
| Headlight | Halogen |
| Indicators | Bulb |
| Taillight | Bulb |
| Daytime Running Lamps | Yes |
| Instrument Console Type | Analogue |
| Tachometer | Analogue |
| Speedometer | Analogue |
| Odometer | Analogue |
| Tripmeter | Analogue |
| No. Of Tripmeters | 1 |
| Multi-function Lock | Yes |
| Key Shutter Lock | Yes |
| Fuel Gauge | Analog |
| Low Fuel Indicator | Yes |
| Low Oil Indicator | Yes |
| Kill Switch | Yes |
| Pass Beam Switch | Yes |
| Seat Opening Switch | Yes |
| Additional Features/Information | 650 mm Seat Length, Viscous Paper Filter |
| Body Graphics | Yes |
| Exhaust Heat Shield | Yes |
| Battery Capacity | 12V / 5AH |
| Carry Hook | Yes |
| Pillion Seat | Yes |
| External Fuel Filling | Yes |
| Braking Type | Combi Brake System |
| Seat Type | Single |
| Rear Footpegs | Yes |
| Underseat Storage | Yes |
| Report Incorrect Specs | |
Mileage and Performance
| Overall Mileage | 50 kmpl |
| Report Incorrect Specs | |
Chassis and Suspension
| Frame Type | Underbone |
| Front Suspension | Telescopic |
| Rear Suspension | Unit Swing |
| Report Incorrect Specs | |
Tyres and Brakes
| Tyre Type | Tubeless |
| Wheel Type | Sheet Metal |
| Wheel Size | Front :-304.8 mm, Rear :-254 mm |
| Tyre Size | Front :-90/90-12 Rear :-90/100-10 |
| Front Tyre Pressure (Rider) | 22 psi |
| Rear Tyre Pressure (Rider) | 29 psi |
| Front Tyre Pressure (Rider & Pillion) | 22 psi |
| Rear Tyre Pressure (Rider & Pillion) | 36 psi |
| Front Brake | Drum |
| Front Brake Size | 130 mm |
| Rear Brake | Drum |
| Rear Brake Size | 130 mm |
| Report Incorrect Specs | |
Riding Position and Seating
| Seat Type | Single |
| Rear Footpegs | Yes |
| Pillion Grab Rail | Yes |
| Report Incorrect Specs | |
Dimensions and Capacity
| Length | 1808 mm |
| Width | 677 mm |
| Height | 1151 mm |
| Wheelbase | 1260 mm |
| Ground Clearance | 160 mm |
| Seat Height | 765 mm |
| Underseat Storage | Yes |
| Front Storage Compartment | Yes |
| Kerb Weight | 106 kg |
| Load Carrying Capacity | 172 kg |
| Fuel Tank Capacity | 5.3 L |
| Fuel Tank Reserve Capacity | 1.3 L |
| Report Incorrect Specs | |
Warranty and Service
| Vehicle Warranty | 3 Years or 36,000 Km |
| 1st Service | 750-1000 Kms / 1 Month |
| 2nd Service | 5500-6000 Kms / 6 Months |
| 3rd Service | 11500-12000 Kms / 1 Year |
| Report Incorrect Specs | |
- Engine and Transmission
- Features
- Mileage and Performance
- Chassis and Suspension
- Tyres and Brakes
- Riding Position and Seating
- Dimensions and Capacity
- Warranty and Service
Last Updated : 2 months ago
Compare Specs of Dio Alternatives
Honda Dio Questions & answers
- FAQ
- Latest Questions
Q) What is the Ex-Showroom Price of Honda Dio?
A) The Ex-Showroom price of Dio in Delhi is 70,809.
Q) What is the Fuel economy of Honda Dio?
A) The fuel economy/Mileage of Dio is 50 kmpl.
Q) What is the fuel tank capacity of Honda Dio?
A) The fuel tank capacity of Dio is 5.3 L.
Q) What is the Curb weight of Honda Dio?
A) The curb weight of Diois 106 kg.
Q) What is the ground clearance of Honda Dio?
A) Honda Dio offers ground clearance of 160 mm.
Q) What are the Color options of Honda Dio?
A) Honda Dio comes with 5 color options - Pearl Igneous Black, Mat Marvel Blue, Imperial Red Metallic, Pearl Igneous Black - Pearl Deep Ground Gray, Mat Axis Gray Metallic.
Q) What type of suspension does the Honda Dio use?
By Bikedekho Experts on 17 Jan 2025
A) The Honda Dio uses a telescopic fork suspension at the front and a rear unit ... Read More
Reply on this answerView all Answer
Q) What are the key differences between the standard and deluxe variants of the Honda Dio?
By Bikedekho Experts on 16 Jan 2025
A) The key differences between the standard and deluxe variants of the Honda Dio ... Read More
Reply on this answerView all Answer
