Specifications of Honda Dio 125
Dio 125 Specs, Features and Price
Honda Dio 125 Brochure
Download Brochure, Discover more!
Honda Dio 125 Specifications
Mileage (Overall) | 48 kmpl |
Displacement | 123.92 cc |
Engine Type | 4 stroke, SI Engine |
No. of Cylinders | 1 |
Max Power | 8.28 PS @ 6250 rpm |
Max Torque | 10.4 Nm @ 5000 rpm |
Front Brake | Disc |
Rear Brake | Drum |
Fuel Capacity | 5.3 l |
Honda Dio 125 Features
External Fuel Filling | Yes |
Service Due Indicator | Yes |
Speedometer | Digital |
Odometer | Digital |
Tripmeter | Digital |
Tachometer | Digital |
Honda Dio 125 Specifications
Engine and Transmission
Engine Type Refers to the design and configuration of the engine. Most petrol bikes typically use either a single-cylinder, twin-cylinder, or occasionally a multi-cylinder (like a four-cylinder) engine. | 4 stroke, SI Engine |
Displacement | 123.92 cc |
Max Torque Represents the highest rotational force output by the engine, usually measured in Newton-meters (Nm) or pound-feet (lb-ft). It indicates the engine's pulling power. | 10.4 Nm @ 5000 rpm |
No. of Cylinders Indicates the total count of combustion cylinders in the engine. Common configurations include single-cylinder, twin-cylinder, and four-cylinder setups. | 1 |
Starting Describes how the engine is initiated. Most petrol bikes use electric starters, kick starters, or both, to commence engine operation. | Self Start Only,Remote Start |
Fuel Supply | Fuel Injection |
Clutch Enables the rider to disconnect the engine from the transmission temporarily, allowing for gear changes and neutral operation. | Automatic Centrifugal Clutch Dry Type |
Bore These measurements describe the diameter (bore) and length (stroke) of the cylinder in the engine. They directly affect an engine's performance characteristics. | 50 mm |
Stroke These measurements describe the diameter (bore) and length (stroke) of the cylinder in the engine. They directly affect an engine's performance characteristics. | 63.113 mm |
Compression Ratio Reflects the ratio of the maximum volume in the cylinder (when the piston is at the bottom) to the minimum volume (when the piston is at the top) during the engine cycle. Higher compression ratios generally lead to more efficient combustion. | 10:0.1 |
Emission Type Specifies the level of emissions produced by the bike, conforming to regulatory standards. Petrol bikes typically adhere to norms like Euro or BS (Bharat Stage) emissions standards. | bs6-2.0 |
Features
Instrument Console This refers to the display panel on a petrol bike that shows essential information like speed, RPM, fuel level, and other indicators such as engine temperature and gear position. | Digital |
Speedometer Displays the current speed of the bike in kilometers per hour (km/h) or miles per hour (mph), providing crucial information for safe riding. | Digital |
Techometer | Digital |
Tripmeter Tracks the distance traveled during a specific journey or trip, enabling riders to monitor their mileage for individual rides. | Digital |
Odometer Shows the total distance covered by the bike since its inception, providing a comprehensive record of its usage | Digital |
Additional Features Of Variant This refers to unique features or upgrades specific to a particular model or variant of the petrol bike, which may include enhanced performance components, aesthetic improvements, or technology integrations. | Seat Length - 708 mm, Battery Indicator, Smart Key Indicator, Side Stand Engine Cutoff (Optional), Silent Start Wth ACG, eSp Technology, Front Pocket, Smart Switch, LED Position Light, Sporty Dual Tip Muffler Protector, Grabrail, |
Seat Type | Single |
Body Graphics Refers to the decorative decals or paint schemes on the bike's bodywork, enhancing its visual appeal. | Racing-Style Graphics |
Passenger Footrest Provides a designated area for the pillion passenger to rest their feet comfortably during rides. | Yes |
Underseat storage | Yes |
Average Fuel economy Indicator | Yes |
Distance to Empty Indicator | Yes |
Features and Safety
Service Due Indicator | Yes |
External Fuel Filling | Yes |
Pass Switch | Yes |
Additional Features This refers to unique features or upgrades specific to a particular model or variant of the petrol bike, which may include enhanced performance components, aesthetic improvements, or technology integrations. | Seat Length - 708 mm, Battery Indicator, Smart Key Indicator, Side Stand Engine Cutoff (Optional), Silent Start Wth ACG, eSp Technology, Front Pocket, Smart Switch, LED Position Light, Sporty Dual Tip Muffler Protector, Grabrail, |
Passenger Footrest Provides a designated area for the pillion passenger to rest their feet comfortably during rides. | Yes |
Engine Kill Switch | Yes |
Real Time Mileage Indicator | Yes |
Mileage and Performance
Overall Mileage | 48 kmpl |
Chassis and Suspension
Body Graphics Refers to the decorative decals or paint schemes on the bike's bodywork, enhancing its visual appeal. | Racing-Style Graphics |
Dimensions and Capacity
Width These dimensions describe the physical size of the bike. Width represents the distance across the widest part of the bike, length is the distance from front to back, and height is the vertical measurement from the ground to the highest point of the bike. | 707 mm |
Length | 1830 mm |
Height | 1172 mm |
Fuel Capacity | 5.3 l |
Ground Clearance | 171 mm |
Wheelbase | 1260 mm |
Kerb Weight | 104 kg |
Additional Storage | Yes |
Electricals
Headlight | LED |
Tail Light | Bulb |
Turn Signal Lamp | Bulb |
Low Fuel Indicator | Yes |
Distance to Empty Indicator | Yes |
Average Fuel economy Indicator | Yes |
Motor & Battery
Peak Power | 8.28 PS @ 6250 rpm |
Drive Type Describes the configuration of the drivetrain, such as front-wheel drive, rear-wheel drive, or all-wheel drive, affecting traction and handling characteristics. | Belt Drive |
Battery Capacity | 12V / 5AH |
Transmission | Automatic |
Underpinnings
Suspension Front | Telescopic |
Suspension Rear | 3-step adjustable Spring loaded hydraulic |
Brakes Front | Disc |
Brakes Rear | Drum |
Tyre Size | Front :-90/90-12 Rear :- 90/100-10 |
Wheel Size | Front :-304.8 mm,Rear :-254 mm |
Wheels Type | Alloy |
Frame | Underbone |
Tubeless Tyre | Tubeless |
