Yamaha Ray Z

Change Scooter
Rs.50,817*
*Ex-showroom Price inDelhi
EMI starts from Rs. 1,472
Get September Offers
Don't miss out on the festive offers this September

Key Specs of Yamaha Ray Z

Engine113 cc
Mileage66 Kmpl
Maximum Speed86 Kmph
Power7.2 bhp @ 7500 rpm
BrakesDrum
Cooling SystemAir Cooled

Yamaha Ray Z Highlights

10 October 2017: Yamaha Ray Z is designed to feature an edgy styling to attract youngsters who crave a reliable city commuting scooter. The peppy engine that presents grunt to the throttle of this agile scooter is the 113cc, air-cooled, 4-stroke single cylinder carbureted engine producing 7.1PS worth of peak power at 7500rpm and a maximum torque of 8.1Nm at 5000rpm. The Yamaha Ray Z had a claimed top speed of 86kmph. The Blue Core technology and the high-ignitability nickel spark plug integrated into the engine makes up for a claimed mileage of 66kmpl. The Ray Z is available in four colour options: Astral Blue, Moon Walk White, True Blue and Regal Red. The appealing body dynamics of the scooter is complemented with its stylish front apron design, distinguished headlamp assembly, and the clear-lens side indicators. The Ray Z relies on front and rear 130mm drum brake units for its braking performance. With the respectable mileage numbers, commendable stability, and edgy design, Yamaha Ray is a good value for money scooter available at Rs 62.395 K (On road, Delhi). The Yamaha Ray Z competes against the likes of – Honda Dio, Hero Duet and Honda Activa i.

Yamaha Ray Z Price

STD66 Kmpl, 113 ccRs.50,817
Get September Offers

Yamaha dealers in Delhi

Yamaha Ray Z User Reviews

  • Excellent
    5
    6
  • Very Good
    4
    8
  • Average
    3
    4
  • Poor
    2
    3
  • Terrible
    1
    1
Your review will give better insights of scooterWrite a Review
  • Positive
  • Critical
  • The Best Scooter with Worst.....

    I am using this scooter from 2014, after too many adjustments still I am getting only 25 KM/L. The power of this........Read More

    P
    Pradeesh
    On: Feb 06, 2018 | 4447 Views
  • Good scooter apart from few.....

    I have had this scooter for a month and straight away it feels as if i have been riding it for months. The poise,........Read More

    A
    Asad
    On: Aug 01, 2017 | 1822 Views
  • sportsrer

    best 1 from yamaha.. the scooter is well refined and smooth. pickup is very high. best for those who likes to stay........Read More

    A
    Anonymous
    On: Apr 08, 2016 | 1383 Views
  • Excellent bike and very.....

    I bought Yamaha ray one year back.Reason for which I choose it is Yamaha engine and stylish.It's a superb scooter........Read More

    L
    Lokesh
    On: Oct 02, 2015 | 1639 Views
  • Good things in small package

    After owning ray after a year, I’m giving my experience below: Pros: 1.Very good build quality and engine........Read More

    K
    Karthik karkera
    On: Oct 02, 2015 | 2641 Views
  • TYRES SPEC OF YAMAHA RAY Z

    I WENT TO BUY YAMAHA RAY Z SCOOTE BUT.AUTHORISE DEALER REFUSE TO DELIVER THE SAME WITH TUBELESS TYRES,THOUGH ITS........Read More

    M
    MAHESH B
    On: Dec 12, 2016 | 1183 Views
  • Yamaha Ray

    Dear friends, I have purchased Yamaha ray on 21 April 2013 from Chennai. My desire was to buy a reliable, easy to........Read More

    P
    Pradeep Shah
    On: Sep 04, 2015 | 6548 Views
  • Yamaha Ray

    Hello friends…….My name is Vishal sharma. Being a bit liker of Yamaha vehicles I bought this vehicle 2 years back.........Read More

    V
    Vishal sharma
    On: Sep 04, 2015 | 2583 Views
  • ray

    I hate this bike buying after so many problems in ray and milege is 39...Read More

    n
    nidhin murali
    On: Nov 17, 2013 | 1702 Views

Yamaha Ray Z Specifications

Mileage (ARAI)66 Kmpl
Front BrakeDrum
Rear BrakeDrum
Fuel Capacity5 L
Engine TypeSingle Cylinder, 4-Stroke, 2-Valve, SOHC
Displacement113 cc
Maximum Speed86 Kmph

Yamaha Ray Z Features

Engine and Transmission

Engine TypeSingle Cylinder, 4-Stroke, 2-Valve, SOHC
Displacement113 cc
Maximum Power7.2 PS @ 7500 rpm
Maximum Torque8.1 Nm @ 5000 rpm
StartingKick and Self Start
Maximum Speed86 Kmph
Cooling SystemAir Cooled
Gear BoxCVT
ClutchDry, Centrifugal
No. of Cylinders1
Drive TypeBelt Drive
Valves (per cylinder)2
Bore50 mm
Stroke57.8 mm
Supply SystemCarburetor
Transmission TypeAutomatic

Tyres and Brakes

Tyre SizeFront :-90/100-10 Rear :-90/100-10
Tyre TypeTubeless
Radial TyresYes
Wheel SizeFront :-10 inch Rear :-10 inch
Front BrakeDrum
Rear BrakeDrum

Performance and Fuel Economy

Mileage (ARAI)66 Kmpl
0-60 Kmph12 Sec

Features and Safety

SpeedometerAnalogue
OdometerAnalogue
ABSNo
EBSNo
Body GraphicsNo
Carry HookNo
Seat TypeSingle
ConsoleAnalogue
Passenger BackrestNo
Step-up SeatNo
Passenger FootrestYes
Underseat StorageYes
Traction ControlNo
Cruise ControlNo
NavigationNo
Quick ShifterNo
Launch ControlNo
Power ModesNo
Adjustable WindscreenNo
Mobile ConnectivityNo

Chassis and Suspension

Front SuspensionTelescopic
Rear SuspensionUnit swing

Dimensions

Length1835 mm
Height1090 mm
Width675 mm
Ground Clearance128 mm
Saddle Height760 mm
Kerb Weight104 Kg
Wheelbase1270 mm
Fuel Capacity5 L

Electricals

IgnitionCDI(Capacitor Discharge lgnition)
Head LampHalogen
Tail LampBulb
Turn Signal LampBulb
Pass SwitchYes
Projector HeadlightNo
Battery TypeMaintenance Free
Battery Capacity12 V - 5 Ah
Low Fuel IndicatorYes
Pilot LampsNo

Yamaha Ray Z Expert Review

Overview

Yamaha Ray Z is one of the first scooters that the company had introduced for the Indian two-wheeler market. Targeted primarily youngsters, the Ray has been designed to look sporty and presents itself as an easy to ride two-wheeler.

The scooter has a sporty design philosophy and it looks compact. The visor, along with the headlamp positioning at the apron make the front end look really appealing. The seat also looks well padded and stylish at the same time. The Yamaha Ray Z comes drenched in an all black theme. The rear end receives a body coloured wing type grab rail that further steps up the visuals.

The Yamaha Ray Z is powered by a 113cc, air-cooled, single cylinder engine mated to an automatic transmission. The Blue Core enabled motor generates respective power and torque of 7bhp and 8Nm.

The Yamaha Ray Z gets 130mm drum brakes at both ends that offer an effective braking. The suspension assembly of this scooter has telescopic forks at the front while the rear end is taken care of by spring aided hydraulic shock absorbers.

This scooter has a total kerb weight of just 104kg, making it an easy to ride and lightweight two-wheeler. The Ray has been fitted with a 5 litre fuel tank. The scooter gets a stylish instrument cluster that has been designed in sync with carbon fibre appearance and hence, looks impressive. The scooter also has a maintenance free battery that actually proves less hefty on the pocket of the rider.

The Yamaha Ray Z is currently available at the company’s dealerships across India at a price of Rs 50,817 (Ex showroom, Delhi). The scooter challenges the likes of TVS Jupiter, Hero Maestro Edge and Honda Activa i. The Ray is available in a total of four colour options to choose from namely Regal Red, Astral Blue, Moon Walk White and True Blue.

Design and Features

The Yamaha Ray Z is a sporty and lightweight offering by the Japanese manufacturer. The front section of this scooter looks sleek and the headlamp is fitted at the apron instead of the conventional front cowl. A small visor is also bolted at the cowl that lends the scooter a sporty touch.

The scooter comes with a comfortable seat and looks stylish as well. The overall body design of the Yamaha Ray Z looks quite compact and sporty at the same time. The wing type rear body grab rail also looks appealing and is one of the style highlights of this scooter.

Yamaha Ray Z has overall body dimensions of 1835mm x 675mm x 1090mm (LxBxH) and has respective wheelbase and minimum ground clearance of 1270mm and 128mm.

Engine and Performance

Powering the Yamaha Ray Z is a 113cc, single cylinder, air-cooled engine that has been linked to an automatic gearbox. The peppy motor is good for churning out a maximum power output of 7bhp along with a peak torque of 8Nm.

The engine is enabled with the company’s patented Blue Core technology that ensures a good combustion efficiency along with a decent fuel economy. The engine is now BS-IV compliant and the company claims a mileage of 66kmpl with this set up. The Yamaha Ray Z can achieve a top speed of 86kmph.

Braking and Handling

The Yamaha Ray Z has been equipped with 130mm drum brakes at the front as well as rear. The suspension system of this scooter comprises of telescopic forks upfront along with spring aided shock absorbers at the rear. Thanks to this, the scooter avails a comfortable ride quality.

The Ray rides on 90/100 sized tyres at the front and rear. These come mounted over 10 inch wheels. The scooter has decent handling characteristics and it feels really nimble in tight city traffic. The straight line stability of the scooter is also satisfactory and you will never feel that the Ray loses its composure when pushed hard.

Safety and Features

The Yamaha Ray Z comes with Automatic Headlamp ON (AHO) facility and hence, the headlight of this two-wheeler stays always ON in order to improve its visibility and minimise chances of an accident. Furthermore, the scooter comes assisted with 130mm drum at both ends. These offer a good feedback and bite and stops the vehicle as and when required. The Yamaha Ray Z also gets a powerful 12V halogen headlamp that offers good illumination at nights.

Yamaha Ray Z Mileage

ARAICityHighwayOverall
66 Kmpl---

Yamaha Ray Z STD gives a mileage of 66 Kmpl as claimed by the Automotive Research Association of India (ARAI).
